Outdoor Optical Fiber Cable

AMPAR

Outdoor Optical Fiber Cable
Features
‧Corrugated ECCS armor for durability and rodent resistance
‧Central Tube cable design provides best fiber protection
‧Inner flexible fiber tube is gel-filled for water blocking
‧Dry water blocking cable core design for less cable preparation time
‧Small cable diameter and light weight for easy duct installation
‧To integrate benefits of both traditional Central Tube and Loose Tube cable
‧Due to flexible bending design, with 7-Wire Galvanized Steel Strand, it can be self-supporting type for aerial application

Description

The Tubes/T MPAR cable is Tube-in-Tube cable structure, this cable contains 2 ~18 flexible fiber loose tubes which are encased in a dry central tube, the inner Gel-filled tube is soft, flexible and can be peeled without any tool. This cable has an overlapping corrugated electrolytic chrome-coated steel (ECCS) tape armor and uses steel wires as strength members. Compared with traditional fiber bundle central core cable and loose tube cable, the cable has advantages in saving time for cable preparation. Fiber counts from 24 to 216 fibers.
Add Inquiry (0)
Added to Inquiry list.
AMPAR

Website integration worksheet

Applications
Local area networks
Outside plant distribution system
Long haul trunking and feeder
Duct or direct buried installation
CATV, CCTV and telecommunication
